MA100 Awning Window

MA100 Awning Window

Ideal for residential homes, apartments, and commercial buildings in Australia, the MA100 aluminium non-thermal break awning and fixed window system meets AS2047 / AS4284 / AS1288 standards, offering durability, ventilation, and a modern look.
Glazing rebate depth: 36mm
Frame visible surface: 35mm
lass specifications:
5mm+12Ar+5mm
6mm+12Ar+6mm
8mm+9Ar+8mm
Glass Configuration:
Clear
Fluted Glass
Custom Coating Colors
Obscured Glass
Single Panel Silver Low-E
Double Silver Low-E
Ultra Clear
Single Panel Bule Low-E
Hardware:
China Brand Single Chain Winder
Doric DS1# 27001 Single chain winder
Doric DS94 # 27001 Double chain winder
Standard Color
Pearl White
2721114G
Monument
2729066M
Black Mall
27219320
Other colors
can be customized
Standard Equipment
Optional Equipment
MAXIMUM PERFORMANCE

Water Tightness :
200Pa

Ultimate Pressure :
2000Pa with no collapse

Air Tightness :
Sealed
At +75 Pa: 0.52 L/s·m²
At -75 Pa: 0.98 L/s·m²
Overall Area: 6.15 m²

GLAZING
5+12A+5
Visible Trans: 63%
U-Value:
Winter Nighttime -1.85W/m²k
Summer Daytime – 1.81W/m²k

6+12A+6
Visible Trans: 72%
U-Value:
Winter Nighttime -1.85W/m²k
Summer Daytime – 1.83W/m²k

Project Presentation
